IntroductionWhen it comes to the world of robotics and el...
- Hign-concerned Chemical: None
- Operating Mode: Auto
- Measuring Capacitance Range: AN101 Digital Multimeter
- Operating Temperature: 0 – 40 ℃
- DIY Supplies: ELECTRICAL
- Measuring Resistance Range: Detection Tool
- Certification: none
- Origin: Mainland China
- Model Number: ANENG AN101 Digital Multimeter
- Measuring Inductance Range: Professional Multimetro
- Brand Name: ANENG
- Dimensions: Multimeter
- DC Current: 200uA/2000uA/20mA/200mA
- AC Current: 200uA/2000uA/20mA/200mA
- AC Voltage: 2V/20V200V/600V
- DC Voltage: 200mv/2V/20V200V/600V
- Display Type: Digital display
- ANENG Model: AN101
ANENG AN101
1999 Counts DC/AC Voltage Current Multimeter
Specification:
- Display: LCD, 1999 counts updates 2/sec
- Polarity Indication: “-” displayed automatically
- Over-range Indication: “OL” displayed
- Range select: auto or manual
- Battery Type: 3V x 2,2032 size (not included)
- Operation Temperature: 0℃ to 40℃, less than 80%RH
- Storage Temperature: -10℃ to 50℃, less than 85%RH
DC Voltage (Auto ranging):
- Range, Resolution & Accuracy
- 200mV, 0.1mV, ±(0.8% of rdg + 5dgts)
- 2V, 1mV, ±(0.5% of rdg + 2dgts)
- 20V, 10mV
- 200V, 100mV
- 600V, 1V, ±(1.0% of rdg + 5dgts)
- Input Impedance: 10MΩ
- Overload Protection: 600V DC/AC rms
- Max. Input Voltage: 600V DC
AC Voltage (Auto ranging):
- Range, Resolution & Accuracy
- 2V, 1mV, ±(1.2% of rdg + 3dgts)
- 20V, 10mV
- 200V, 100mV
- 600V, 1V, ±(1.2% of rdg + 8dgts)
- Input Impedance: 10MΩ
- Frequency Range: 40Hz ~ 400Hz
- Overload Protection: 600V DC/AC rms
- Response: Average, calibrated in rms of sine wave
- Max. Input voltage: 600V AC rms
DC Current:
- Range, Resolution & Accuracy
- 200µA, 0.1µA, ±(0.8% of rdg + 5dgts)
- 2000µA, 1µA
- 20mA, 10µA
- 200mA, 100µA
- Overload Protection: F0.5A/600V fuse
- Max. Input Current: 500mA
- Voltage Drop: 200µA and 20mA ranges: 20mV
- 2000µA and 200mA ranges: 200mV
AC Current:
- Range, Resolution & Accuracy
- 200µA, 0.1µA, ±(1.0% of rdg + 5dgts)
- 2000µA, 1µA
- 20mA, 10µA
- 200mA, 100µA
- Overload Protection: F0.5A/600V fuse
- Max. Input Current: 500mA
- Voltage Drop: 200µA and 20mA ranges: 20mV
- 2000µA and 200mA ranges: 200mV
- Frequency Range: 40Hz ~ 400Hz
- Response: Average, calibrated in rms of sine wave
Package included:
- 1 x Digital Multimeter (battery is not included)
- 1 x Test Leads
Note:
- Please allow 0-1cm errors due to manual measurement.
- Item color displayed in photos may be showing slightly different on your computer monitor since monitors are not calibrated same.
